Introduction

The Pentax K-1 Mark II is a new professional full-frame DSLR camera that replaces the original K-1 model that was released in 2016. The Mark II is virtually identical to its predecessor in both form and function, incorporating a new accelerator unit to improve noise reduction and auto-focusing speed and adding an upgraded Pixel Shift Resolution System II with a newly developed Dynamic Pixel Shift Resolution mode for handheld shooting. In all other regards the two cameras are the same.

The Pentax K-1 Mark II is available in black for £1799 / $1999 body-only. In the US it will also be available with the FA 28-105mm F3.5-5.6 ED DC WR zoom lens for $2399.

Ease of Use

The Pentax K-1 Mark II is virtually identical to the original K-1 model, so if you don’t know anything about that camera, we strongly suggest that you head over and read our in-depth Pentax K-1 review first. In this rather brief review, we’re going to focus on the new features that the Mark II offers over and above the original version.

The new Mark II version differs in three main ways – it offers improved high sensitivity performance, high-speed Auto Focus, and image resolution through the new handheld Pixel Shift Resolution mode.

Pentax K-1 Mark II
Front of the Pentax K-1 Mark II

The ISO range of the K-1 II now runs from ISO 100 up to a whopping ISO 819200. As you’d maybe expect, the resulting images at such a high ISO speed are bordering on unusable (see our Image Quality page for 100% crops of each ISO speed), but more usefully ISO performance is about a stop better than on the original K-1, not really becoming visible until ISO 3200. So if you ever felt limited by the ISO range on the K-1, the new Mark II version slightly improves things.

The K-1 II’s AF Tracking algorithm has been revised to improve tracking accuracy of fast-moving subjects in the AF Continuous mode. The original K-1 was pretty sluggish in this regard, and although the new Mark II is quicker at identifying the main subject and more reliable at tracking, we still wouldn’t describe it as a great camera for sports photography.

Pentax K-1 Mark II
Rear of the Pentax K-1 Mark II

The new handheld Dynamic Pixel Shift Resolution mode is more successful, building on the original Pixel Shift Resolution offered by the K-1. The latter is still present, requiring the camera to be mounted on a tripod. The in-body SR (shake reduction) mechanism is used to move the image sensor unit by a single pixel pitch at a time to capture four shots, which are then merged into a single image to generate an ultra high-definition image.

The new handheld Dynamic Pixel Shift Resolution mode differs by switching on the image stabilisation system, taking four similar shots, then combining them into one aligned ultra high-definition image, all whilst hand-holding the camera. It’s much like the method employed by recent smartphones like the Huawei P20 Pro, and it similarly works well with both still and moving subjects.

Pentax K-1 Mark II
Top of the Pentax K-1 Mark II

There are a couple of notable drawbacks, though. Firstly, you really need to use a shutter speed that’s fast enough to avoid camera shake, and secondly, unlike the normal Pixel Shift Resolution mode, it doesn’t cancel out the Bayer color array, which can lead to unwanted artifacts, moire and less detail in the resulting image. Finally, it also takes much longer for the camera to process the final image, about 20 seconds in total, so you’ll only want to use it for that “special” shot, as it completely locks the camera up.

And that’s it for the improvements offered by the Pentax K-I Mark II, other than a change to the name badge on the front and the base of the camera.

Pentax K-1 Mark II
The Pentax K-1 Mark II In-hand

Unfortunately, though, there is one area where the Mark II takes a backwards step, namely battery life. Whereas the original K-1 offered 760-shot battery life, the new K-1 II has 670-shot life according to CIPA standards, presumably because of the new accelerator unit.

Current Pentax K-1 owners can actually get their cameras upgraded to the new functions offered by the Mark II – simply send your camera back to Pentax between May 21st and 30th September, pay the $550 / £450 service charge, and voila, your camera’s main circuit board will be replaced to add the new functions featured in the new Pentax K-1 MK II and  the current SR logo, positioned in the lower left corner of the camera’s front panel, will be replaced with the SR II logo. This is almost certainly a cheaper way of upgrading to the Mark II than selling your original camera and buying the newer model.

Quick run-down of the differences between the Mark I and Mark II:
Pentax K-1 Mark II Pentax K-1 (Mark I)
New Handheld Pixel Shift mode
Upgraded Improved AF speed / performance
ISO Range ISO100 – 819200 ISO100 – 204800
APS-C fps 6.4fps 6.5fps
New Night LCD mode Added with firmware update
Battery Life 670 760

Image Quality

All of the sample images in this review were taken using the 36 megapixel Best JPEG setting, which gives an average image size of around 12Mb.

The Pentax K-1 Mark II produced photos of excellent quality. Noise is well controlled by the Pentax K-1 Mark II throughout the expanded range of 100-819200, first starting to appear at ISO 3200 and becoming more easily detectable at the faster settings of ISO 6400-25600 when viewing images at 100% magnification on screen (particularly in the RAW files). The fastest settings of 51200-819200 look much better on paper than in reality. Colour saturation is commendably maintained throughout the ISO range.

Pixel Shift Resolution is an effective technology that creates bigger files, finer detail and generates more accurate colours, even if the subject moves or the camera shakes slightly. The new Handheld mode does what its name suggests and allows you to create high-resolution images without having to use a tripod, although at the expense of less detail and more colour artifacts than using the tripod modes.

Pentax K 1 MarkII (4)

Image stabilisation via the camera body is a great feature that works very well when hand-holding the camera in low-light conditions or when using the telephoto end of the zoom range. An added bonus is that it works with any lens that you attach to the K-1 Mark II. The night photograph was excellent, with the maximum shutter speed of 30 seconds and Bulb mode allowing you to capture enough light in all situations.

The Digital Filters quickly produce special effects that would otherwise require you to spend a lot of time in the digital darkroom, while the Custom Images can usefully be tweaked to suit. The D-Range options help make the most out of both the shadows and highlights in a high-contrast scene (and it works for both JPEG and RAW files), while the HDR mode greatly expands the dynamic range of a JPEG by combining three differently exposed images in-camera.

The multi exposure mode combines between two and 2,000 different JPEG or RAW images into a single photo, while the anti-aliasing simulator helps to reduce moire without the need for an actual optical filter.

Noise

There are 14 ISO settings available on the Pentax K-1 Mark II. Here are some 100% crops which show the noise levels for each ISO setting, with JPEG on the left and the RAW equivalent on the right:

JPEG

RAW

ISO 100 (100% Crop)

ISO 100 (100% Crop)

iso100.jpg iso100raw.jpg

ISO 200 (100% Crop)

ISO 200 (100% Crop)

iso200.jpg iso200raw.jpg

ISO 400 (100% Crop)

ISO 400 (100% Crop)

iso400.jpg iso400raw.jpg

ISO 800 (100% Crop)

ISO 800 (100% Crop)

iso800.jpg iso800raw.jpg

ISO 1600 (100% Crop)

ISO 1600 (100% Crop)

iso1600.jpg iso1600raw.jpg

ISO 3200 (100% Crop)

ISO 3200 (100% Crop)

iso3200.jpg iso3200raw.jpg

ISO 6400 (100% Crop)

ISO 6400 (100% Crop)

iso6400.jpg iso6400raw.jpg

ISO 12800 (100% Crop)

ISO 12800 (100% Crop)

iso12800.jpg iso12800raw.jpg

ISO 25600 (100% Crop)

ISO 25600 (100% Crop)

iso25600.jpg iso25600raw.jpg

ISO 51200 (100% Crop)

ISO 51200 (100% Crop)

iso51200.jpg iso51200raw.jpg

ISO 102400 (100% Crop)

ISO102400 (100% Crop)

iso102400.jpg iso102400raw.jpg

ISO 204800 (100% Crop)

ISO 204800 (100% Crop)

iso204800.jpg iso204800raw.jpg

ISO 409600 (100% Crop)

ISO 409600 (100% Crop)

iso409600.jpg iso409600raw.jpg

ISO 819200 (100% Crop)

ISO 819200 (100% Crop)

iso819200.jpg iso819200raw.jpg
Pixel Shift Resolution

The in-body SR (shake reduction) mechanism is used to move the image sensor unit by a single pixel pitch at a time to capture four shots (the use of a tripod is strongly recommended). Pixel Shift Resolution merges those shots into a single image to generate an ultra high-definition image. This method differs from the traditional Bayer method, which acquires only a single element of color information for single pixel, by acquiring all RGB color information for individual pixel. This difference makes it excellent for detail and color reproduction, creating super high-definition images. This also prevents false colors from occurring theoretically, and also has a high-sensitivity noise reduction effect when compared to normal shooting.

The new handheld Dynamic Pixel Shift Resolution mode differs, though, by switching on image stabilisation, taking four similar shots, then combining them into one aligned ultra high-definition image. Unlike the normal Pixel Shift Resolution mode, it doesn’t cancel out the Bayer color array, which can lead to unwanted artifacts, moire and less detail in the resulting image. It does have an advantage under indoor lights, however, as it uses the mechanical shutter rather than the electronic one, as used by the normal Pixel Shift Resolution mode, which can result in unwanted banding.

Off

Motion Correction On

pixel_shift1.jpg pixel_shift2.jpg
Motion Correction Off Handheld
pixel_shift3.jpg pixel_shift4.jpg

Off

Motion Correction On

pixel_shift5.jpg pixel_shift6.jpg
Motion Correction Off Handheld
pixel_shift7.jpg pixel_shift8.jpg
File Quality

The Pentax K-1 Mark II has 3 different JPEG file quality settings available, with Best being the highest quality option, and it also supports RAW (Pentax’s PEF format and Adobe DNG). Here are some 100% crops which show the quality of the various options, with the file size shown in brackets.

Best (20.3Mb) (100% Crop)

Better (8.71Mb) (100% Crop)

quality_best.jpg quality_better.jpg

Good (4.08Mb) (100% Crop)

RAW (43.8Mb) (100% Crop)

quality_good.jpg quality_raw.jpg
Night

The Pentax K-1 Mark II lets you dial in shutter speeds of up to 30 seconds and has a Bulb mode as well, which is very good news if you are seriously interested in night photography. The shot below was taken using a shutter speed of 30 seconds at ISO 100.

Shake Reduction

The Pentax K-1 Mark II has a Shake Reduction mechanism built into the camera body, which allows you to take sharp photos at slower shutter speeds than other digital cameras. To test this, we took 2 handheld shots of the same subject with the same settings. The first shot was taken with Shake Reduction turned off, the second with it turned on. Here is a 100% crop of the image to show the results. As you can see, with Shake Reduction turned on, the images are sharper than when it’s turned off.

Shutter Speed / Focal Length

Shake Reduction Off (100% Crop)

Shake Reduction On (100% Crop)

1/6 / 28mm antishake1.jpg antishake1a.jpg
1/15 / 105mm antishake2.jpg antishake2a.jpg
AA Filter Simulator

Rather than an optical anti-aliasing filter in the camera, the K-1 has an anti-aliasing simulator instead, which can be turned off (default setting) or on to either the Type1 or Type2 setting.

Off

Off (100% Crop)

aa_filter_01.jpg aa_filter_01a.jpg

Type1

Type1 (100% Crop)

aa_filter_02.jpg aa_filter_02a.jpg

Type2

Type2 (100% Crop)

aa_filter_03.jpg aa_filter_03a.jpg
D-Range

Similar to Nikon’s D-lighting, Sony’s DRO, and Olympus’ Shadow Adjustment Technology, Pentax’s D-Range allows you to correct the highlights (On or Off) and/or the shadows (3 different levels) before taking a JPEG or RAW image. Although this option is always at your disposal, remember that it is meant to be used in strong, contrasty lighting at base ISO. Below you can see a comparison between Off and both highlight and shadow correction set to on/full strength; the difference is mainly noticeable in the shadowed areas on the left and right sides of the photo.

Off

On

drange1.jpg drange2.jpg
HDR Capture

The Pentax K-1 Mark II’s HDR Capture option takes three images with different exposures, and then records a single image that combines the properly exposed parts of each one, expanding its dynamic range. Here is an example which was shot with the five different modes (Off, 1, 2, 3 and Advanced). Although the K-1 can microalign images before combining them, allowing hand-held HDR shots to be taken, for best results it’s important to always use a tripod to prevent camera shake from blurring the HDR image, and it doesn’t work very well for moving subjects.

Off

HDR1
hdr_01.jpg hdr_02.jpg
HDR2 HDR3
hdr_03.jpg hdr_04.jpg
Advanced
Custom Images

Pentax’s Custom Images, similar to Nikon’s Picture Styles and Canon’s Picture Controls, are preset combinations of different sharpness, contrast, saturation and colour tone settings. You can change the saturation, hue, high/low key, contrast and sharpness for each of the seven options. They are shown below in the following series, which demonstrates the differences.

Bright

Natural

custom_image_01.jpg custom_image_02.jpg

Portrait

Landscape

custom_image_03.jpg custom_image_04.jpg

Vibrant

Radiant

custom_image_05.jpg custom_image_06.jpg

Muted

Flat
custom_image_07.jpg custom_image_08.jpg

Bleach Bypass

Reversal Film

custom_image_09.jpg custom_image_10.jpg

Monochrome

Cross Processing

custom_image_11.jpg custom_image_12.jpg
Digital Filters

The Pentax K-1 Mark II offers nine different Digital Filters, which allow you to quickly apply an artistic effect to a photo before taking it (JPEG images only). They are shown below in the following series, which demonstrates the differences. Note that applying the Digital Filters slows the camera down somewhat, as it has to process the image for a few seconds after it’s taken.

Extract Color

Replace Color

digital_filter_01.jpg digital_filter_02.jpg

Toy Camera

Retro

digital_filter_03.jpg digital_filter_04.jpg

High Contrast

Shading

digital_filter_05.jpg digital_filter_06.jpg

Invert Color

Unicolor Bold

digital_filter_07.jpg digital_filter_08.jpg
Bold Monochrome
Multi-exposure

The Pentax K-1 Mark II has a fantastic multi-exposure mode that allows you to combine between two and 2,000 (!) different JPEG or RAW images into a single photo. Here is an example.

Multi-exposure


Sample Images

This is a selection of sample images from the Pentax K-1 Mark II camera, which were all taken using the 36 megapixel Best JPEG setting. The thumbnails below link to the full-sized versions, which have not been altered in any way.

1/100s · f/2.8 · ISO 400 – 70mm (35mm)

1/50s · f/8 · ISO 800 – 24mm (35mm)

1/320s · f/2.8 · ISO 200 – 70mm (35mm)

1/200s · f/8 · ISO 200 – 36mm (35mm)

1/160s · f/11 · ISO 200 – 24mm (35mm)

Product Images

Pentax K-1 Mark II
Front of the Pentax K-1 Mark II
Pentax K-1 Mark II
Front of the Pentax K-1 Mark II
Pentax K-1 Mark II
Side of the Pentax K-1 Mark II
Pentax K-1 Mark II
Side of the Pentax K-1 Mark II
Pentax K-1 Mark II
Side of the Pentax K-1 Mark II
Pentax K-1 Mark II
Side of the Pentax K-1 Mark II
Pentax K-1 Mark II
Rear of the Pentax K-1 Mark II
Pentax K-1 Mark II
Rear of the Pentax K-1 Mark II / Image Displayed
Pentax K-1 Mark II
Rear of the Pentax K-1 Mark II / Info Screen

Pentax K-1 Mark II
Rear of the Pentax K-1 Mark II / Info Screen
Pentax K-1 Mark II
Rear of the Pentax K-1 Mark II / Main Menu
Pentax K-1 Mark II
Rear of the Pentax K-1 Mark II / Live View
Pentax K-1 Mark II
Rear of the Pentax K-1 Mark II / Tilting LCD Screen
Pentax K-1 Mark II
Rear of the Pentax K-1 Mark II / Tilting LCD Screen
Pentax K-1 Mark II
Top of the Pentax K-1 Mark II
Pentax K-1 Mark II
Bottom of the Pentax K-1 Mark II
Pentax K-1 Mark II
Side of the Pentax K-1 Mark II
Pentax K-1 Mark II
Side of the Pentax K-1 Mark II
Pentax K-1 Mark II
Front of the Pentax K-1 Mark II
Pentax K-1 Mark II
Front of the Pentax K-1 Mark II
Pentax K-1 Mark II
Memory Card Slot
Pentax K-1 Mark II
Battery Compartment

Specifications

Type
Camera Type TTL autofocus, auto-exposure SLR digital-still camera
Sensor
Type CMOS-Sensor, Primary color filter

AA Filter Simulator: Moiré reduction using SR unit. OFF/Type1/Type2/Bracket (2 or 3 images)

Size 35.9 x 24.0 mm
Total Pixels Approx. 36.77 megapixels
Effective Pixels Approx. 36.40 megapixels
Still [35mm Full Frame]

JPEG: L(36M: 7360×4912) M(22M:5760×3840) S(12M:4224×2816) XS(2M:1920×1280),

RAW: (36M:7360×4912)

[APS-C size]

JPEG: L(15M: 4800×3200) M(12M:4224×2816) S(8M:3456×2304) XS(2M:1920×1280),

RAW: (15M:4800×3200)

Pixel Shift Resolution: High resolution Pictures based on the use of each Pixel for all RGB-Color Information – Now also for moving subjects.

Movie Full HD (1920×1080, 60i/50i/30p/25p/24p), HD (1280×720, 60p/50p)
Colour Depth 14bit in RAW Mode PEF and DNG
Sensitivity ISO AUTO/100 to 819200 (EV steps can be set to 1EV, 1/2EV or 1/3EV)
Shake Reduction 5 Axis Sensor Shift Shake Reduction (SR II)
Sensor Cleaning Image sensor cleaning using ultrasonic vibrations «DR II»

Sensor-shift shake reduction (SR II: Shake Reduction) (5axis)

Pixel Shift Resolution Pixel Shift Resolution II: High resolution Pictures based on the use of each Pixel for all RGB-ColorInformation.
Traditional Mode with the use of Electronic Shutter, Tripod is recomended, Handheld Mode with 4 single pictures
White Balance Type: Method using a combination of the CMOS image sensor and the light source detection sensor

AUTO WB, Multi Auto WB, Daylight, Shade, Cloudy, Fluorescent Light (D:Daylight Color, N:Daylight White, W:Cool White, L:Warm White), Tungsten Light, CTE, Manual WB (up to 3 settings), Color Temperature Configuration (up to 3 settings), Copying the white balance setting of a captured image

Fine Adjustment: Adjustable ±7 steps on A-B axis or G-M axis

Lens
Mount KAF4, KAF3, KAF2 (power zoom compatible), KAF, KA mount lens
Usable lenses KAF4, KAF3, KAF2 (power zoom compatible), KAF, KA mount lens
Focusing System
Type Type TTL: phase-matching autofocus
Functions Focus Sensor: SAFOX 12, 33 point (25 cross type focus points in the center)

Brightness Range: EV-3 to 18 (ISO 100 / at normal temperature)

AF mode: Single AF (AF.S), Continuous AF (AF.C)

AF Point Selection: Spot, Select, Expanded Area (S, M, L), Zone select, Auto (33 AF points)

AF assist Dedicated LED AF assist light
Viewfinder
Type Pentaprism Finder
Field of View Approx. 100%
Magnification Approx. 0.70x (50mm F1.4 at infinity)
Focusing screen Fixed Natural-Bright-Matte III focusing screen
Indication Viewfinder Overlay: AF Points, Grid Display, Electronic Level, AF Frame, Spot Metering Frame, Crop

Eye-Relief Length: Approx. 20.6mm (from the view window), Approx 21.7mm (from the center of lens)

Diopter adjustment Approx. -3.5m to + 1.2m-1
Screen
Type Wide viewing angle TFT color LCD, Air-gapless glass, Flexible-tilt.

Size: 3.2 inch (aspect ratio 3:2)

Resolution Approx. 1.037K dots
Playback Adjustment: Brightness, Saturation and Colors adjustable

Outdoor View Setting: Adjustable ±2 step

Liveview
LiveView Type: TTL method using image sensor

Focusing Mechanism: Contrast detection (Face detection, Tracking, Multiple AF points, Select, Spot)

Focus Peaking: ON/OFF

Display: Field of View approx. 100%, Magnified view (up to 16x),

Grid Display (4×4 Grid, Golden Section, Scale display, Square 1, Square 2,

Grid Color: Black/White ), Histogram, Bright area warning, Composition Adjustment

Shutter
Type Electronically controlled vertical-run focal plane shutter
* Electronic shutter when using Pixel Shift Resolution
Speed 1/8000 to 30 sec., Manual: 1/8000 to 30 sec. (1/3EV steps or 1/2EV steps), Bulb
Exposure system
Metering TTL open aperture metering using 86K pixel RGB sensor, Multi-segment, center-weighted and spot metering
Exposure Modes Scene Analyze Auto, Program, Sensitivity Priority, Shutter Priority, Aperture Priority, Shutter & Aperture Priority, Manual, Bulb, Flash X-sync Speed, USER1, USER2, USER3, USER4, USER5
Metering Range EV-3 to 20 (ISO100 at 50mm F1.4)
Auto Exposure Lock Button type (timer type: two times the meter operating time set in Custom Setting);

Continuous as long as the shutter button is halfway pressed

Compensation ±5EV (1/2EV steps or 1/3EV steps can be selected)
Flash
Type Flash Control: Contrast-control-sync and High-speed sync requires 2 or more dedicated external flash guns

Sync Speed: 1/200 sec.

Exposure Compensation -2.0 to + 1.0EV
Exposure Parameters
Modes Drives modes

Mode Selection: Single Frame, Continuous (H, M, L), Self-timer (12s, 2s, Continuous), Remote Control (0s., 3s., Continuous), Bracketing (2, 3 or 5 frames), Mirror-up, Multi-Exposure, Interval Shooting, Interval Composite, Star Stream
* Bracketing, Interval Shooting, Interval Composite, Interval Movie Record, Multi Exposure and Star Stream are possible to use with Self-timer/Remote Control.

Continuous Shooting:
[35mm Full Frame] Max. approx. 4.4 fps, JPEG ( L: ★★★ at Continuous H): up to approx. 70 frames,
RAW: up to approx. 17 frames
Max. approx. 3.0 fps, JPEG L: ★★★ at Continuous M): up to approx. 100 frames,
RAW: up to approx. 20 frames
Max. approx. 0.7 fps, JPEG ( L: ★★★ at Continuous L): up to approx. 100 frames,
RAW: up to approx. 100 frames

[APS-C size] Max. approx. 6.4 fps, JPEG ( L: ★★★ at Continuous H): up to approx. 100 frames,
RAW: up to approx. 50 frames
Max. approx. 3.0 fps, JPEG L: ★★★ at Continuous M): up to approx. 100 frames,
RAW: up to approx. 70 frames
Max. approx. 1.0 fps, JPEG ( L: ★★★ at Continuous L): up to approx. 100 frames,
RAW: up to approx. 100 frames

Multi-Exposure: Composite Mode (Additive/Average/Bright), Number of Shots (2 to 2000 images)

Interval Shooting:

[Interval Shooting] Interval: 2s. to 24h./ Standby
Interval: Min.1s. to 24h., Number of shots: 2 to 2000 images
Start Interval: Now/Self-timer/Remote Control/Set Time

[Interval Composite] Interval: 2s. to 24h./ Standby
Interval: Min.1s. to 24h., Number of shots: 2 to 2000 images
Start Interval: Now/Self-timer/Remote Control/Set Time
Composite Mode: Additive/Average/Bright, Save Process: On/Off

Capture setting

Custom Image: Auto Select, Bright, Natural, Portrait, Landscape, Vibrant, Radiant, Muted, Flat, Bleach Bypass, Reversal Film, Monochrome, Cross Processing

Sharpness level: Fine Sharpness and Extra Sharpness improve sharpness and gives much better details

Cross Processing: Randum, Preset 1-3, Favorite 1-3

Digital Filter: Extract Color, Replace Color, Toy Camera, Retro, High Contrast, Shading, Invert Color, Unicolor Bold, Bold Monochrome

Clarity: Adjustable ±4 step

HDR: Auto, HDR1, HDR2, HDR3, Advanced HDR, Exposure bracket value adjustable, Automatic composition correction function

Lens Correction: Distortion Correction, Peripheral Illumin. Correction, Lateral Chromatic Aberration Correction, Diffraction Correction

Dynamic Range compensation: Highlight Correction, Shadow Correction

Noise Reduction: Slow Shutter Speed NR, High-ISO NR

Horizon Correction: SR On: correction up to 1 degrees, SR Off: correction up to 2 degrees

Composition Adjustment: Adjustment range of ±1.5mm up, down, left or light (1mm when rotated); rotating range of 1 degree

Electronic Level: Displayed in viewfinder and LCD panel (horizontal and vertical);
displayed on LCD monitor (horizontal and vertical)

Movie
Recording File Format: MPEG-4 AVC/H.264 (MOV)

Recorded Pixels: Full HD(1920×1080, 60i/50i/30p/25p/24p), HD (1280×720, 60p/50p)

Sound: Built-in stereo microphone, external microphone (Streo recording compatible)
Recording Sound Level adjustable, Wind Noise Reduction

Recording Time: Up to 25 minutes or 4GB; automatically stops recording if the internal temperature of the camera becomes high.

Custom Images: Aoto Select, Bright, Natural, Portrait, Landscape, Vibrant, Radiant, Muted, Flat, Bleach Bypass, Reversal Film, Monochrome, Cross Processing

Cross Processing: Randum, Preset 1-3, Favorite 1-3

Digital Filter: Extract Color, Replace color, Toy Camera, Retro, High Contrast, Shading, Invert Color, Unicolor Bold, Bold Monochrome

Interval Movie Record:

[Interval Movie] Recorded Pixels: 4K/FullHD/HD, File Format: Motion JPEG (AVI), Interval: 2s. to 24h./ Standby
Interval: Min.1s. to 24h., Number of shots: 8 to 2000 images (8 to 500 images at 4K),
Start Interval: Now/Self-timer/Remote Control/Set Time

[Star Stream] Recorded Pixels: 4K/FullHD/HD, File Format: Motion JPEG (AVI), Interval: 2s. to 24h./ Standby
Interval: Min.1s. to 24h., Number of shots: 8 to 2000 images (8 to 500 images at 4K),
Start Interval: Now/Self-timer/Remote Control/Set Time,
Fade-out: Off/Low/Medium/High
Playback
Digital Filter Base Parameter Adj, Extract Color, Replace Color, Toy Camera, Retro, High Contrast, Shading, Invert Color, Unicolor Bold, Bold Monochrome, Tone Expansion, Sketch, Water Color, Pastel, Pasteurization, Miniature, Soft, Starburst, Fish-eye, Slim, Monochrome
Options Playback View:

Single frame, multi-image display (6,12, 20, 35, 80 segmentation), display magnification (up to 16, 100% display and quick magnification available), rotating, histogram (Y histogram, RGB histogram), bright rea warning, Auto Image Roation, detailed inf, Copyright Information (Photographer, Copyright holder), Folder Display, Calendar Filmstrip Display, Slide Show, GPS information (latitude, longitude, altitude, Coordinated Universal Time, Orientation)

Delete:

Delete single image, delete all, select & delete, delete folder, delete instant review image

RAW Development:

RAW file select: Select Single Image, Select Multiple Images, Select a folder

RAW Development Parameter: White Balance, Custom Image, Sensitivity, Clarity, Skin Tone, Digital filter, HDR, Pixel Shift Resolution, Shadow Correction, High-ISO NR, Distortion Correction, Peripheral Illumin. Corr., Lateral Chromatic Aberration Correction, Diffraction Correction, Color Fringe Correction, File Format (JPEG/TIFF), Aspect Ratio, JPEG Recorded Pixels, JPEG Quality, Color Space

Edit: Image Rotation, Color Moiré Correction, Resize, Cropping (Aspect ratio and Slant adjustment available), Movie Edit (Divide or delete selected frames), Capturing a JPEG still picture from a movie, Saving RAW data in buffer memory, Image Copy

Storage
External Storage Medium: SD, SDHC and SDXC Memory Card (Conforms to USH-1 standards)

Dual SD slot: Sequential Use, Save to Both, Separate RAW/JPG, Image copy between slots possible

File Format RAW (PEF/DNG), JPEG (Exif 2.30), DCF2.0 compliant

Quality Level RAW (14bit): PEF, DNG, JPEG:*(Best),**(Better),***(Good), RAW + JPEG
simultaneous capturing available

Color Space: sRGB, AdobeRGB

File Name “IMGP****” or User assingned file name

File name numbering: Sequential, Reset

Special Features
Features GPS/Electronic Compass

GPS: GPS Logging (Logging Interval, Logging Duration, Memory Card Options), GPS Time Sync

Electronic Compass: Available

Astrotracer: Possible

Satellites: GPS, QZSS, SBAS(WAAS/ EGNOS/ GAGAN/ MSAS)

Reception Frequency: L1 1575.42MHz

Recorded Information: Latitude, Longitude, Altitude, Time (UTC), Direction

Geodesics World Geodetic System (WGS84)

GPS Logging: KML format, Logging Interval: 5/10/15/30sec. /1min., Logging Duration: 1-24hr. (Up to 9hours at Logging Interval 5sec. Up to 18hrs. at Logging Interval 10sec.)

Electronic Compass: Azimuth calculation using triaxial geomagnetic sensor and triaxial acceleration sensor, True north standard

Customization

USER Mode: Up to 5 settings can be saved

Custom Functions: 26 items

Mode Memory: 17 items

Custom Button: Fx1 Button, Fx2 Button (One Push File Format, Outdoor View Setting, Flash Mode, Pixel Shift Resolution, Shake Reduction, Horizon Correction, Electronic Level) AF Button (AF1/ AF2/ Cancel AF) Preview Dial (Optical Preview/Digital Preview)
Various settings for the action of the e-dials in each exposure mode can also be saved.

AF Customization: AF.S: Focus-priority/ Release-priority
1st Frame Action in AF.C: Release-priority/Auto/Focus-priority
Action in AF.C Continuous: Focus-priority, Auto, FPS-priority
Hold AF Status: OFF, Low, Medium, High
AF in Interval Shooting: Locks focus at 1st exposure, Adjusts focus for each shot
AF with Remote Control: Off/On

Operation Control: Type 1: E-Dial, EV Compensation, ISO, Green Button, AE Lock

Lock: Type 2: 4-way controller, AF point change button, Change AF Point, OK Button, Menu Button

Text Size: Standard, Large

World Time: World Time settings for 75 cities (28 time zones)

AF fine Adjustment: ±10 step, Uniform adjustment, Individual adjustment (up to 20 can be saved)

Illumination Settings: LCD Panel (High/Low/Off), Backside Controls (High/Low/Off), Lens Mount (On/Off), Card Slot/Connector (On/Off)

Indicator Lamps: Wi-Fi (High/Low/Off), GPS (High/Low/Off), Self-timer (On/Off), Remote Control (On/Off)

Copyright Information: Names of “Photographer” and “Copyright Holder” are embedded to the image file. Revision history can be checked using the provided software.

Operating environnement

Temperature: -10°C ~ 40°C (14°F ~104°F)
Humidity: 85% or less (no condensation)
Dust and Water protected: 87 Sealings protecting camera against Dust, Rain and Spraywater. Camera is not water protected.

Language English, French, Germany, Spanish, Portuguese, Italian, Dutch, Danish, Swedish, Finnish, Polish, Czech, Hungarian, Turkish, Greek, Russian, Korean, Traditional Chinese, Simplified Chinese, Japanese
Wireless LAN
Standards IEEE 802.11b/g/n
Frequency (Center Frequency) 2412MHz ~ 2462MHz (1ch ~ 11ch)
Security Authentication: WPA2, Encryption: AES
Interface
Interface Connection Port: USB2.0 (micro B), external power supply terminal, external release controller terminal, X-synch socket, HDMI output terminal (Type D), stereo miscrophone input terminal, Headphone terminal

USB Connection: MSC/PTP

Power
Source Battery Type: Rechargeable Lithium-ion Battery D-LI90

AC Adapter: AC Adapter Kit K-AC132 (Optional)

Performance Battery Life:

Number of recordable images: 670

Playback time: Approx. 340 minutes

* With a fully-recharged Rechargeable Lithium-ion Battery. Tested in compliance with CIPA
standard. Actual results may vary depending on the shooting condition.

Body
Height 110mm
Width 136.5mm
Depth 85.5mm
Weight Approx. 1010g (Including dedicated battery and 1x SD Memory Card), Approx. 925 (body only)
Accessories
Kit Content Rechargeable-Ion Battery D-LI90(B) – 39830

Battery Charger D-BC90 – 39832

Finder Cap for me – 31011

AC plug cord D-CO2E – 39475

PENTAX Strap O-ST162 – 38477

Eyecup FT – 30128

Hotshoe cover FK – 31040

Body mount Cap KII – 31000

Synchro Terminal 2P Cap – 31042

PENTAX K-1 Triangular Ring – 38599

PENTAX K-1 Protective Cover – 38600

Software (CD-ROM) S-SW162 – 38557

Optional Rechargeable-Ion Battery D-LI90(B) – 39830

AC Adapter Kit K-AC167

Battery Charger Kit K-BC90E – 39834

Battery Grip D-BG6 – 38607

PENTAX Remote Control O-RC1 – 39892

Cable switch CS-205 – 37248

PENTAX AF 201 FG Electro Flash W/Case – 30458

PENTAX AF 540 FGZ II W/Case – 30456

PENTAX AF 360 FGZ II W/Case – 30438

Strap O-ST1401 black – 38613

Strap O-ST1401 red – 38614

Conclusion

The Pentax K-1 Mark II remains an excellent 35mm full-frame DSLR camera, but it feels more like a stop-gap release rather than a fully-fledged successor to the original K-1.

18 months is quite a long time in the fast-moving world of digital imaging, so the fact that Pentax have only added less than a handful of new features to the K-1 II is rather disappointing, especially for owners of the K-1. We’d hesitate to recommend that those users upgrade to the K-1 II, either by selling their original cameras and buying the new version or by taking advantage of the rather unique upgrade service, as the three key improvements aren’t collectively worth it.

Extending the ISO range to 819200 sounds great on paper, but looks terrible in reality, with the real benefit being a 1-stop improvement in noise performance much lower down the range. Similarly, the AF system is a little snappier and more reliable when tracking moving subjects, but not massively so compared to the original K-1. Finally, the handheld pixel shift mode does allow you to take sharp, high-resolution still images without having to use a tripod, but only with a number of caveats that limit its overall usefulness.

Add the £200 / $200 increase to the RRP of the K-1 II and the reduction in battery life, and we’re left wondering why you’d choose to upgrade to the Pentax K-1 Mark II. For new would-be owners, though, it’s a much more attractive proposition that still holds its own despite the rather modest improvements.

(photographyblog.com, http://bit.ly/2vqURtQ)

Comments

comments

Share on FacebookPin on PinterestShare on StumbleUponTweet about this on TwitterShare on LinkedIn
