Introduction

The Olympus OM-D E-M1 Mark II is the new flagship professional model in Olympus’s OM-D well-established series of compact system cameras. The E-M1 Mark II boasts a tough dust-, drip- and freeze-proof magnesium alloy body, a 20.4-megapixel Four Thirds image sensor with 121 phase-detection all cross-type auto-focus points, a 5-axis sensor-shift image stabiliser offering up to 6.5 stops of compensation, and the dual quad-core TruePic VIII processing unit which provides 18fps continuous shooting with focus tracking or 60fps without. Featuring a Micro Four Thirds lens mount, the camera also sports a high-resolution 2.36m-dot electronic viewfinder, vari-angle LCD touchscreen, hybrid AF system, focus peaking function, dual SD-card slots, Wi-Fi connectivity and in-camera HDR exposure blending. The Olympus OM-D E-M1 Mark II is currently available for £1849/$1999 body-only in the UK and US, respectively.

Kết quả hình ảnh cho Olympus OM-D E-M1 Mark II Review

Ease of Use

The Olympus OM-D E-M1 Mark II is Olympus’s new flagship Micro Four Thirds camera. Outwardly looking a lot like its 3-year-old predecessor, the Olympus OM-D E-M1, the new Mark II model boasts a large number of significant improvements to its image quality, handling and especially its performance. Just like the original E-M1, it also boasts a tough dust-, drip- and freeze-proof magnesium alloy body.

Like the Olympus PEN-F, the OM-D E-M1 II comes equipped with a 20-megapixel Four Thirds sensor, which offers some resolution advantage over the 16-megapixel imager of the E-M1 Mark I. Given that the size of the sensor is (obviously) unchanged, this increase in pixel count translates into a smaller pixel pitch. With no change in sensor architecture, this could lead to a reduction in dynamic range and signal-to-noise ratio. However, Olympus are telling us that this is a completely new sensor with cutting-edge technology that enables it to actually offer a wider dynamic range and even a slight improvement in noise performance, something that we take a look at on the Image Quality page.

The Olympus OM-D E-M1 Mark II’s 5-axis in-body image stabiliser can now work synergistically with the in-lens stabilisation system incorporated into certain lenses – such as the new 12-100mm PRO zoom that we tested the camera with – to provide a claimed 6.5-stop advantage when shooting hand-held, surpassing any other camera that we’ve ever tested.

Olympus OM-D E-M1
Front of the Olympus OM-D E-M1 Mark II

The Olympus OM-D E-M1 Mark II is slightly bigger and heavier than the original model, weighing in at 500g body only and measuring 134.1 x 90.9 x 68.9mm. The most easily noticeable difference is the much more prominent hand-grip, which makes it even easier to get a firm hold on the camera with three fingers whilst operating the shutter button with your right forefinger. The grip and indeed most of the front of the camera is covered in a leatherette-like textured material. Once again there are two buttons next to the lens mount. By default these controls are assigned to one-touch white balance and depth-of-field preview but, like almost everything else on the OM-D E-M1 Mark II, they can be reprogrammed to perform different tasks if you so desire.

On the top of the camera, to the left of the viewfinder housing (when viewed from above and behind) there is a cluster of controls comprised of two raised buttons and a power switch. Each of the two buttons provides access to two sets of settings. Press the first one and you can adjust the camera’s drive modes and HDR settings with the rear and front control dials, respectively. Hit the second and you can cycle through the various focus and metering modes offered by the camera. The placement of the on/off switch might well raise a few eyebrows as it means you need to use your left hand to turn on the camera, which is hardly an ideal solution. Actually, this is a design nod to the Olympus OM-1 film camera that had its power switch in virtually the same location – which is all nice and well, but we’d still prefer it to be in a position where you can easily reach it with your right thumb or forefinger.

Moving over to the other side of the viewfinder hump, we find a traditional mode dial with a not-so-traditional locking pin in the middle. On most other cameras that have a lockable dial, you need to hold down the centred button while turning the dial – on the Olympus OM-D E-M1 Mark II, the mode dial locks with one press of the locking pin and unlocks with a second press, which is a clever idea. The dial itself offers the usual P, A, S and M modes, plus a dedicated Movie mode and separate positions for Art Filters, Intelligent Auto and 3 separate Custom modes for quick access of custom settings banks, or Mysets in Olympus parlance.

Olympus OM-D E-M1
Rear of the Olympus OM-D E-M1 Mark II

The Olympus OM-D E-M1 Mark II inherits the still innovative 2×2 Dual Control system. This is comprised of two top-mounted control wheels and a function lever that’s pretty easy to reach with your right thumb.  The function lever has two settings. In the first position, moving the control dial on the front of the camera adjusts the aperture while the dial on the back adjusts the shutter speed. On the second setting, the dials change the ISO value and white balance respectively. You can also configure the switch’s operation too – for example, you can turn it into a handy AF/MF toggle if that makes more sense to you. The remaining controls on the camera’s top plate include the already mentioned shutter release, plus a dedicated Movie Record button and the customisable Function 2 button.

The rear plate features more or less the same controls as on the original E-M1. The camera’s back is dominated by a large, vari-angle rear touchscreen which can now be tilted to the side and rotated to the front for easier selfies, a big improvement on the older model’s more restricted range of movement. This LCD panel has the same resolution, 1,037,000 dots, as its predecessor, and capacitive touchscreen technology. The Info, Menu, Playback and Delete buttons have all been carried over from the original model, although they have been slightly rearranged, the Fn1 button is still on the upper right part of the rear plate, and there is still an AEL/AFL button encircled by the afore-mentioned function lever and a Display button located to the left of the viewfinder.

The Olympus OM-D E-M1 Mark II also has the same viewfinder, offering a 2.4-million-dot resolution, 1.48x magnification and a 21mm eyepoint. It also has a refresh rate of 120fps and a latency of just 6 milliseconds, which should enable you to engage in true decisive-moment photography and to follow your subject relatively easily in continuous shooting mode. As befits a camera of this class, the finder has an eye proximity sensor that allows the camera to switch from the LCD screen to the EVF automatically when you lift it up to your eye. The E-M1 Mark II’s electronic viewfinder also “gains up” in low light, making it arguably more usable than an optical finder.

Olympus OM-D E-M1
Side of the Olympus OM-D E-M1 Mark II

The Olympus OM-D E-M1 Mark II makes do without a pop-up flash but comes bundled with a tiny FL-LM3 flash unit (first introduced with the OM-D E-M5 Mark II camera), which clips into the external flash hotshoe. Naturally you can also use more powerful system flashes with the E-M1 Mark II – such as the powerful new FL-900R, the FL-36R, the FL-600R or the FL-50R – but these are of course sold separately.

Focusing is one area where the Olympus OM-D E-M1 Mark II offers a clear improvement over the original E-M1. The on-sensor phase-detection system has been completely overhauled and now includes 121 cross-type AF points covering almost the entire frame, rather than the E-M1’s 37 phase-detection points, which enables better continuous AF performance especially with low-contrast subjects in low-contrast light, as well as fast focusing with “regular” Four Thirds lenses, mounted via an adapter. Low-light auto focus continues to be excellent – the system managed to focus down to -2EV (as long as there was something to focus on) even without the use of the focus assist lamp. This is seriously low light, about the same as a landscape lit only by moonlight and nothing else.

Additionally, the focusing system has received a speed boost – the Olympus OM-D E-M1 II can shoot 18 full-resolution frames per second with continuous autofocus, when using the electronic shutter, a massive improvement on the E-M1’s 6.5fps rate. The Olympus OM-D E-M1 II’s mechanical shutter is rated for 200,000 actuations and is capable of shooting up to 15 frames per second. Additionally, the camera has a Silent mode, in which it uses an electronic shutter capable of high-speed continuous shooting at up to 60fps with the focus fixed (18fps with C-AF). A key contributor to this performance boost is the company’s TruePix VIII image processing unit, which features two quad-core chips.

Olympus OM-D E-M1
The Olympus OM-D E-M1 Mark II In-hand

Manual focus enthusiasts will be delighted to learn that the Olympus E-M1 has a focus peaking feature, which enables precise focusing even without magnifying into the live view feed. The OM-D E-M1 II offers a new Pro Capture mode that starts recording full-resolution shots when you half-press the shutter release. Plus, in addition to shooting at the sensor’s native resolution, there are two High Res Shot Modes in which the camera combines 8 exposures to produce one “supersized” JPEG image with a resolution of either 25 or 50 megapixels. As before, taking advantage of this mode requires the camera to be mounted on a tripod.

The implementation of Wi-fi the OM-D E-M1 Mark II is actually quite good. You first need to download a free app for your smartphone (Android and iOS versions are both available), but after that, everything is pretty straightforward. You simply touch the Wi-Fi icon on your camera’s display to set up a connection. The Olympus OM-D E-M1 Mark II will provide you with an SSID and password, but you do not need to type in either of them – just launch the app on your phone and scan the QR code displayed by your camera with your phone. This is nearly as fast as using NFC (Near-Field Communication), a feature that the OM-D E-M1 doesn’t offer. Once the connection is established, you can download images from the camera to your smartphone, or use the latter to remotely control the E-M1 Mark II. The level of control provided is quite good – you can choose from a variety of shooting modes, set aperture, sensitivity, shutter speed and white balance, choose a drive mode, and focus on practically any part of the frame, all remotely.

The OM-D E-M1 Mark II movie mode is much improved. It can now record cine-standard 4K videos at 24fps with a bit rate of up to 237Mbps in the DCI 4K mode (4096 x 2160 pixels) or UHD 4K footage at 30fps and a 102Mbps bit-rate. Full HD 1080p and HD 720p recording is also supported. It can use its excellent 5-axis sensor-shift image stabiliser which translates into surprisingly smooth hand-held footage, even when using a medium telephoto lens. Manual exposure can be enabled for videos, although you do have to rotate the mode dial to the Movie position to take advantage of this. (You can start filming in practically any other shooting mode too, but in that case, videos will always be recorded with auto exposure.)

Olympus OM-D E-M1
Top of the Olympus OM-D E-M1 Mark II

The Olympus OM-D E-M1 Mark II has a time-lapse photography mode, which allows you to capture up to 999 frames at user-specified intervals. You can also tell the camera when to start the sequence, which comes in handy if you want to set up the camera well in advance. The E-M1 Mark II will save each shot in the format of your choice – ORF or JPEG – and can optionally create a time-lapse video in-camera, which you can play back on the rear screen, or upload to a website like Vimeo or YouTube. While shooting raw and creating a video afterwards on your PC gives you more control over grading, sharpening etc., the in-camera option is nice to have when shooting JPEG or raw+JPEG, as it is obviously much faster.

The Olympus OM-D E-M1 Mark II has a complex, multi-level menu system that might not seem intuitive at first sight, so reading the manual is a good idea before starting to explore it. The good news is that these menus are mainly there to allow you to set up the camera exactly the way you want it to be set up – once you’re done with that, you’ll seldom need to delve into the menus again, courtesy of the large number of external controls (12 in total) as well as the excellent Super Control Panel, which is basically an interactive status display inherited from older Olympus cameras.

The Olympus OM-D E-M1 Mark II is powered by a more powerful 1720mAh BLH-1 lithium-ion battery, which promises a lifespan of around 440 shots according to CIPA testing standards, plus faster charging. The camera saves images and movies on SD, SDHC and SDXC memory cards (up to UHS-II speed class), and there are now two memory card slots, so it’s possible to make instant back-ups in the field by saving your shots on two cards simultaneously. Unfortunately only slot is UHS-II compatible. Wired connection ports include a USB 3 Type C connector, an HDMI port and standard 3.5mm stereo microphone and headphone jacks. Moving on to the bottom of the camera, the tripod socket has been brought in line with the lens’s optical axis – which is great news if you are into serious panoramic photography but not if you’ve been counting on being able to use your old HLD-7 portrait grip with this new camera.

Image Quality

All of the sample images in this review were taken using the 20 megapixel SuperFine JPEG setting, which gives an average image size of around 12Mb.

The Olympus OM-D E-M1 Mark II produced images of outstanding quality during the review period. It produces noise-free images at ISO 64 to 1600, with limited noise starting to appear at ISO 3200. ISO 6400 exhibits quite visible noise and loss of fine detail, and the fastest settings of ISO 12800 and 25600 are even noisier but still usable for small prints and web use.

The images were a little soft straight out of the camera at the default sharpening level and ideally require further sharpening in an application like Adobe Photoshop, or you can change the in-camera setting if you don’t like the default results. The Art Filters produce special effects that would otherwise require you to spend a lot of time in the digital darkroom. The image stabilisation system works excellently for both stills and video, even when hand-holding the camera at very slow shutter speeds.

Noise

There are 9 ISO settings available on the Olympus OM-D E-M1 Mark II. The base sensitivity is ISO 200 but there is an expanded low sensitivity setting equivalent to ISO 64. These crops demonstrate the image quality at each setting.

JPEG

ISO 64 (100% Crop)

ISO 200 (100% Crop)

ISO 400 (100% Crop)

ISO 800 (100% Crop)

ISO 1600 (100% Crop)

ISO 3200 (100% Crop)

ISO 6400 (100% Crop)

ISO 12800 (100% Crop)

ISO 25600 (100% Crop)

File Quality

The file quality settings available on the Olympus OM-D E-M1 Mark II include Basic, Normal, Fine and Superfine for JPEGs, and you can also shoot in Olympus’s proprietary ORF raw file format. Do note that the Superfine setting must first be enabled from the menu in order to appear among the selectable quality options.

SuperFine (100% Crop) Fine (100% Crop)
Normal (100% Crop) Basic (100% Crop)
Night

The  Olympus OM-D E-M1 Mark II offers exposure times as long as 60 second in a metered exposure or up to 30 minutes in bulb mode, which is excellent news for anyone seriously interested in night photography. Live Bulb mode allows you to view the progression of exposure during a bulb exposure in real-time and a live view histogram shows how the exposure is built-up across all points of the image. The following picture was taken handheld at a shutter speed of 1/60 second, aperture of f/2.8 at ISO 3200.

Night

Image Stabilisation

The Olympus OM-D E-M1 Mark II comes with a five-axis sensor-shift image stabilisation (IS) system, which allows you to take sharp hand-held photos at slower shutter speeds than with cameras that lack this feature, up to an incredible 6.5 shutter speed steps of correction. The following 100% crops are taken from images taken with the M.ZUIKO Digital ED 12-100mm 1:4.0 IS PRO lens at a shutter speed of 1/15th of a second, with and without IS. The image stabilisation system also works during video capture, producing remarkably steady hand-held footage most of the time.

Focal Length / Shutter Speed

Off (100% Crop)

On (100% Crop)

12mm / 1/15th Second
100mm / 1/15th Second
High Resolution Shot

The Olympus OM-D E-M5 Mark II can create a 50 megapixel JPEG or an 80 megapixel RAW file in the High Resolution Shot mode, achieved by shifting the sensor in half-pixel steps and capturing eight images over a period of one second. Olympus recommends that you mount the camera on a tripod or other stable surface to obtain sharp results.

Off (100% Crop) On (100% Crop)
Off (100% Crop) On (100% Crop)
Art Filters

The Olympus OM-D E-M1 Mark II offers 14 ‘art filters’, which allow you to quickly apply an artistic effect to a photo before taking it. Art filters are easily accessible via a dedicated slot on the mode dial.

Pop Art

Soft Focus

Pale&Light Color

Light Tone

Grainy Film

Pin Hole

Diorama Cross Process
Gentle Sepia Dramatic Tone
Key Line Watercolor
Vintage Partial Color
Continuous Auto-focusing

The Olympus OM-D E-M1 Mark II camera can shoot at up to 18fps with continuous autofocusing and metering.

To test this out, I hand-held the E-M1 Mark II and the 12-100mm f/4 lens, and then recorded an eagle that was flying towards me. Nothing else was used to support the camera, and the weather was frankly terrible (raining and overcast), yet the E-M1 II managed to nail the focus on the majority of frames. Here’s a video showing the 45 still shots that I took, played back at a very slow frame rate so that you can judge more clearly if the eagle is in focus or not.

Pro Capture Mode

The new Olympus OM-D E-M1 Mark II camera has an innovative Pro Capture mode which should make it easier to capture that decisive moment. Simply set the shooting mode dial to the Pro Capture setting, then press and hold the shutter release button halfway. The E-M1 Mark II will then continuously buffer a series of full resolution 20 megapixel JPEG / RAW images until you fully press the shutter button, at which point it will capture the image plus the 14 previous frames. If you want to take full advantage of the E-M1 Mark II’s amazing 60fps shooting rate, continue to keep the shutter release fully depressed to take up to an additional 99 frames.

I was able to try the Pro Capture mode out whilst photographing an archer who was shooting arrows through a series of water balloons. I half-pressed the shutter release button, then fully pressed it when the archer let go of his arrow, and continued to hold down the shutter to fire at the full 60 frames per second rate. The Olympus OM-D E-M1 Mark II was able to capture a sequence of images with the balloons intact, then the arrow going through the ballons with the water exploding. And remember, the E-M1 Mark II can do this whilst capturing full-resolution, 20 megapixel Raw files!

Here’s a 2 second video clip at 30fps showing the 60 frames.

And here are the same 60 frames laid out in a grid.

Olympus OM-D E-M1 Mark II - Pro Capture Mode

4K Video and 5-Axis Image Stabilisation

The Olympus OM-D E-M1 Mark II camera can shoot 4K video whilst taking advantage of its in-body 5-Axis image stabilization, which compensates for all types of camera shake.

To test this out, I hand-held the E-M1 Mark II whilst sat in a moving car, and then recorded a pair of horses that were running alongside at roughly the same speed. Nothing else was used to support the camera, and this was the first and only take that I was able to record. Here’s the resulting footage.

Sample Images

This is a selection of sample images from the Olympus OM-D E-M1 Mark II camera, which were all taken using the 20 megapixel SuperFine JPEG setting. The thumbnails below link to the full-sized versions, which have not been altered in any way.

1/100s · f/2.8 · ISO 200

1/800s · f/2.8 · ISO 1600

1/1600s · f/2.8 · ISO 1600

1/160s · f/1.8 · ISO 400

1/160s · f/1.8 · ISO 640

1/3s · f/2.8 · ISO 64

Product Images

Olympus OM-D E-M1
Front of the Olympus OM-D E-M1 Mark II

Olympus OM-D E-M1
Front of the Olympus OM-D E-M1 Mark II

Olympus OM-D E-M1
Side of the Olympus OM-D E-M1 Mark II

Olympus OM-D E-M1
Side of the Olympus OM-D E-M1 Mark II

Olympus OM-D E-M1
Side of the Olympus OM-D E-M1 Mark II

Olympus OM-D E-M1
Side of the Olympus OM-D E-M1 Mark II

Olympus OM-D E-M1
Rear of the Olympus OM-D E-M1 Mark II

Olympus OM-D E-M1
Rear of the Olympus OM-D E-M1 Mark II

Olympus OM-D E-M1
Rear of the Olympus OM-D E-M1 Mark II / Image Displayed

Olympus OM-D E-M1
Rear of the Olympus OM-D E-M1 Mark II / Turned On

Olympus OM-D E-M1
Rear of the Olympus OM-D E-M1 Mark II / Main Menu

Olympus OM-D E-M1
Tilting LCD Screen

Olympus OM-D E-M1
Tilting LCD Screen

Olympus OM-D E-M1
Top of the Olympus OM-D E-M1 Mark II

Olympus OM-D E-M1
Bottom of the Olympus OM-D E-M1 Mark II

Olympus OM-D E-M1
Side of the Olympus OM-D E-M1 Mark II

Olympus OM-D E-M1
Side of the Olympus OM-D E-M1 Mark II

Olympus OM-D E-M1
Front of the Olympus OM-D E-M1 Mark II

Olympus OM-D E-M1
Front of the Olympus OM-D E-M1 Mark II

Olympus OM-D E-M1
Memory Card Slot

Olympus OM-D E-M1
Battery Compartment

Specifications

Type

  • Body material

    Magnesium alloy body

  • Lens mount

    Micro Four Thirds

Image Sensor

  • Type

    4/3” Live MOS sensor

  • Effective pixels

    20.4 Megapixels

  • Filter array

    Primary colour filter (RGB)

  • Aspect ratio & area

    4:3 / 17.3 x 13.0mm

  • Full resolution

    21.8 Megapixels

Engine

  • Type

    TruePic VIII

Filter

  • Dust reduction filter

    Supersonic Wave Filter

Viewfinder

  • Type

    Electronical Viewfinder

  • Pixel number

    2.360K dots

  • Diopter adjustment

    Yes; ‑4.0 ‑ +2.0 diopters / built‑in type

  • Field of view

    Approx. 100%

  • Magnification

    Max. 1.48x with a 50mm lens set to infinity at ‑1 dioptre (depending on selected viewfinder style)

  • Eye point

    21mm at ‑1 dioptre from eyepiece lens

  • Style

    3 styles selectable

  • Displayed information
    • Aperture value
    • Shutter speed
    • AF frame (super impose)
    • AF confirmation mark
    • AF lock
    • Auto bracket
    • Battery check
    • Exposure compensation indicator
    • Exposure compensation value indicator
    • Exposure level indicator
    • Exposure mode
    • Flash
    • FP flash
    • IS activating mode
    • Metering mode
    • Number of storable sequential pictures
    • White balance
    • Level Gauge
    • Highlight & Shadow
    • Live Pre-view function
    • Histogram
  • Brightness adjustment

    Adaptive Brightness Technology / Manual settings: +/‑ 7 levels

  • Correction of colour temperature

    +/‑ 7 levels

  • S-OVF

    Expands the Live View dynamic range

  •

    *Available in the EVF when in P, A, S and M modes. Art filter, WB and exposure are not reflected in EVF.

Live View

  • Displayed information
    • Aperture
    • Shutter speed
    • Auto bracket
    • AE lock
    • Focus mode
    • Shooting mode
    • Battery check
    • IS activating mode
    • Face / Eye detection mode
    • Record mode
    • ISO
    • Sequential shooting mode
    • White Balance
    • Metering mode
    • Exposure compensation value
    • AF frame display
    • AF confirmation mark
    • Shooting information
    • Spot metering area
    • Super FP
    • Flash status
    • Touch Panel Condition
    • Focal length
    • Flash mode
    • Histogram
    • Level Gauge
    • Highlight & Shadow
    • Focus peaking
    • Number of storable pictures
    • Custom
    • Face detection
    • Flash intensity
    • WiFi
  • Field of view

    Approx. 100%

  • Magnification levels

    3 / 5 / 7 / 10 / 14x

  • Dynamic range expansion

    When in HDR1 or HDR2

  • Display modes
    • Comparison
    • Grid (4 types)
    • Grid
    • Histogram
    • Level Gauge
    • Magnified View
    • Standard information
    • Off

Image Stabiliser

  • Type

    Sensor shift

  • Modes

    Five‑dimensional, vertical or horizontal activation, automatic

  • Effective Compensation Range

    Up to 5.5 EV steps (CIPA)

Focusing System

  • Method

    TTL phase difference detection system, contrast detection system

  • Focus areas

    121 points * / All target, Group target (9‑areas or 5‑areas), Single target

  •

    800 points / Manual selection in Magnified View Mode

  •

    * All cross type

  • AF lock

    Yes; Locked by first position of shutter release button in single AF mode, AE/AF lock button (customised)

  • Modes
    • Manual focus
    • Preset MF*
    • Single AF
    • Continuous AF
    • Single AF + MF
    • AF Tracking
  •

    * Distance setting values are rough estimates and only AF lenses can be used.

  • AF illuminator

    Yes

  • Full time AF

    Yes

  • Manual focus

    Yes; With enlarged focusing area or focus peaking

  • Face Detection extension
    • Eye Detect AF: Off
    • Left side priority
    • Near side priority
    • Right side priority
  • Predictive AF

    Yes

  • AF tracking

    Yes; Available in continuous AF mode

  • Focus peaking
  • Colour selection

    White, black, red, yellow

  • Intensity

    High / Normal / Low

  • Back light effect

    On / Off

  • Focus Bracketing Mode
  • Number of images

    3 – 999shots

  • Step size

    10levels

  •

    Compatible with: All Micro Four Thirds AF lenses

Exposure System

  • Modes
    • Programme automatic
    • Aperture priority
    • Shutter priority
    • Manual
    • Bulb
    • Time
    • Movie
    • HDR
    • My Mode
    • Custom shooting
    • Custom 1
    • Custom 2
  • Exposure compensation

    +/‑ 5 EV (1, 1/2, 1/3 steps)

  •

    Note: Monitor and EVF displays only up to ±3 EV.

  • Exposure bracketing

    2 / 3 / 5 frames (+/‑ 1/3, 2/3, 1 EV steps)

  •

    7 frames (+/‑ 1/3, 1/2, 2/3 EV steps)

  • ISO bracketing

    3 frames (1/3, 1/2, 1 EV steps)

  • AE lock

    Yes

  • My Mode

    4 settings storable

  • Enhancement function

    Digital Shift (horizontal and vertical compensation can be performed simultaneously)

  •

    Shadow Adjustment Technology

  • HDR bracketing

    3 / 5 frames (+/‑ 2 / 3 EV steps)

  •

    7 frames (+/‑ 2 EV steps)

Multi-Exposure

  • Max. number of frames

    2 frames (shooting)

  •

    3 frames (editing)

  • Auto gain control

    Yes

  • Frame assistance

    Live View

Light Metering

  • Method

    TTL open aperture light metering

  • Zones

    324 zones Multi‑pattern Sensing System

  • Detection range

    ‑2 ‑ 20 EV (17mm f2.8, ISO 100)

  • Modes
    • ESP light metering
    • Spot metering
    • Centre weighted metering
    • Highlight
    • Shadow

Art Filter

  • Modes
    • Pop Art
    • Soft Focus
    • Pale & Light Colour
    • Light Tone
    • Grainy Film
    • Pin Hole
    • Diorama
    • Cross Process
    • Dramatic Tone
    • Gentle Sepia
    • Key Line
    • Water colour
    • Vintage
    • Partial Colour*
  • Variation / Effect

    Available

  • Art Filter bracketing

    Art Filters selectable

Sensitivity

  • Auto

    (customisable, default ISO LOW ‑ 6400)

  • Manual

    ISO LOW ‑ 25600 in 1/3 or 1 EV ISO steps

Shutter

  • Shutter type

    Computerised focal‑plane shutter

  • Self timer

    2s / 12s / Custom

  • Durability

    200000shots

Shutter Speeds

  • Shutter speed range

    1/8000 ‑ 60s (in 1/3, 1/2, 1 EV steps)

  • Bulb mode

    Up to 30 minutes (selectable longest time in the menu, default: 8 minutes)

  • High res shot
  • Shutter type

    Electronic shutter

  • Shutter speed

    1/8000 ‑ 8s

  • Start delay

    0, 1/8, 1/4, 1/2, 1, 2, 4, 8, 15. 30s

  • Resolution

    JPEG: 8160 x 6120 / 5760 x 4320 RAW: 10368 x 7776

  •

    Equivalent to 50M / 25M pixel sensor (8 shots combined into a single JPEG using sensor shift)

  •

    Available in P/A/S/M mode

  • Anti shock mode
  • Shutter type

    Electronic first curtain shutter

  • Shutter speed

    1/320* ‑ 60s

  • Start delay

    0, 1/8, 1/4, 1/2, 1, 2, 4, 8, 15, 30s

  •

    * For speeds over 1/320 sec., mechanical shutter will automatically be selected.

  • Silent mode
  • Shutter type

    Electronic shutter

  • Shutter speed

    1/32000 ‑ 60s

  • Start delay

    0, 1/8, 1/4, 1/2, 1, 2, 4, 8, 15. 30s

White Balance

  • AUTO WB system

    Advanced detection system with Live MOS sensor

  • Manual White balance (One-Touch)

    Yes

  • White balance bracketing

    3 frames / +/‑ 2, 4, 6 mired steps

  • One-touch white balance

    4 custom settings can be registered

  • Custom WB

    1 setting can be registered at Kelvin temperature (2000K ‑ 14000K)

  • Preset values
    • Tungsten
    • Flourescent 1
    • Sunlight
    • Flash
    • Overcast
    • Shade
    • Underwater
  • Auto Flash adjustment

    Off / Auto WB / Flash

  • Keep warm colour

    On / Off

Sequence Shooting

  • Speed (H)

    Approx. 15fps

  • Max. number of frames: RAW 84 / JPG (LN): 117
  • Speed (L)

    10fps

  • Max. number of frames: RAW 148 / JPG (LN): Up to card capacity
  • Silent mode
  • Speed (H)

    Approx. 60fps

  • Max. number of frames: RAW 48 / JPG (LN): 48
  • Speed (L)

    Approx. 18fps

  • Max. number of frames: RAW 77 / JPG (LN): 105
  • Pro Capture mode
  • Speed (H)

    Approx. 60fps

  • Speed (L)

    Approx. 18fps

  • Pre-shutter Frames

    0 – 14frames (recorded by half release prior to full release)

  • Frame count limiter

    1- 99frames / Off (unlimited frames) (incl. pre‑shutter frames)

  • Conditions

    Memory card: TOSHIBA SDHC UHS‑II R95 W90 EXCERIA™

  •

    When using the M.Zuiko Digital ED 12‑40mm f2.8 Pro

  •

    Maximum sequential shooting speed may be affected by several factors including lens used, brightness, aperture, shutter speed, and ISO setting.

  •

    When ISO is 8000 or above, 30 fps becomes the maximum sequential shooting speed. The actual shooting speed may become slower than the set shooting speed by a few frames per second. When using ISO Bracketing, performance will be affected at ISO 2000 or above.

Image Processing

  • Colour space

    sRGB / AdobeRGB

  • Sharpness + Contrast

    5 levels

  • Contrast

    5 levels

  • Saturation

    5 levels

  • Black & White filter

    Yellow, Orange, Red, Green

  • Black & White toning

    Sepia, Blue, Purple or Green in Black & White mode

  • Picture mode
  • Gradation

    4levels (auto, high key, normal, low key)

  • Engine

    TruePic VIII

  • Art Filter bracketing

    Available

  • Tele converter effect

    2x

Internal Flash

  • Modes
    • AUTO
    • Manual
    • Manual (Full, 1/4, 1/16, 1/64)
    • Red-eye reduction
    • Slow synchronisation with red-eye reduction
    • Slow synchronisation
    • Slow synchronisation 2nd curtain
    • Fill-in
    • Off
    • TTL-Auto
    • FP Manual
    • FP TTL Auto
  • Type

    Detachable flash with bounce capability (bundled)

  • Flash compensation

    +/‑ 3 EV / 1/3, 1/2, 1 EV steps

  • Guide number

    12.9 (ISO 200)

  • X-sync speed

    1/250s / 1/8000s (Super FP Mode)

External Flash Control

  • X-sync speed

    1/250s / 1/8000s (Super FP Mode)

  • Type

    TTL AUTO, AUTO, MANUAL, FP TTL AUTO, FP MANUAL

  • Modes
    • Auto
    • Red-eye reduction
    • Slow synchronisation
    • 2nd curtain and slow synchronisation
    • Fill-in for exclusive flash
    • Manual
  • Intensity

    +/‑ 3 EV (1/3, 1/2, 1 EV steps)

  •

    Note: Some functions are only available if they are supported by the external flash.

Wireless Flash Control

  • Number of channels

    4 channels

  • Compatible external flash

    FL‑36R, FL‑50R, FL‑300R, FL‑600R, FL‑900R, STF‑8

  • Control method

    Triggered and controlled by bundled flash

  • Group setting

    4 groups

  •

    Available when used together with cameras compatible with the Olympus wireless RC flash system.

Monitor

  • Monitor type

    Vari‑angle LCD ‑ Touch Panel

  • Monitor size

    7.6cm / 3.0” (3:2)

  • Resolution

    1037K dots

  • Brightness adjustment

    +/‑ 7 levels

  • Colour balance

    +/‑ 7 levels Vivid (default) / Natural

  • Touch Control fucntions
    • AF area enlargement
    • AF area selection
    • Art Filter
    • Enlargement
    • Enlargement playback
    • Frame forward/backward
    • Live Guide
    • Scene Modes
    • Shooting mode
    • Shutter release
    • Super Control Panel
    • Wifi connection

Level Gauge

  • Detection

    2‑axis

  • Display

    Rear display and viewfinder

Super Control Panel

  • Displayed information
    • Battery indicator
    • Record mode
    • Shutter speed
    • Aperture value
    • Exposure compensation indicator
    • ISO
    • AE bracketing
    • AF frame
    • Focus mode
    • AEL notification
    • Face detection
    • Number of storable frames
    • Metering mode
    • Exposure mode
    • Exposure level view
    • Flash compensation value
    • Colour space
    • Gradation
    • Colour saturation compensation value
    • Sharpness compensation value
    • Contrast compensation value
    • White balance
    • White balance compensation value
    • Noise reduction
    • Flash mode
    • Drive mode
    • Internal temperature warning
    • Histogram

Recording Formats

  • RAW

    12bit

  • RAW & JPEG

    Yes; parallel recording

  • JPEG

    Yes

  • Aspect ratio

    4:3 / 3:2 / 16:9 / 6:6 / 3:4

  • MPO (3D)

    Yes

Image Size

  • RAW

    5184 x 3888 compressed

  •

    5184 x 3888 Fine (compression: 1/4)

Still Image Recording

  • EXIF

    2.3

  • DCF

    Yes

  • RAW

    Yes

  • Dual SD card settings

    Standard, Auto Switch, Dual Independent, Dual Same

  •

    When two cards are inserted, card to be saved on to or to be viewed can be designated.

Movie Recording System

  • Recording format

    MOV(MPEG‑4AVC/H.264), AVI(Motion JPEG)

  • Time code

    Rec run / Free run

  •

    Drop frame / Non‑drop frame

  • Image Stabilisation Mode

    Yes; Sensor shift

  •

    M‑IS1 (Image sensor shift and electronic image stabilizer with multi motion IS)

  •

    M‑IS2 (Image sensor shift with multi motion IS)

  • 4K Movie quality

    4096 x 2160 (C4K) / 24p / IPB (approx. 237 Mbps)

  •

    3840 x 2160 (4K) / 30p, 25p, 24p / IPB (approx. 102 Mbps)

  • HD Movie quality

    Full HD 1920 x 1080 (16:9) / 30p, 25p, 24p / ALL‑I(A‑I), IPB(SF, F, N) (MOV)

  •

    Full HD 1920 x 1080 (16:9) / 60p, 50p / IPB(SF, F, N) (MOV)

  •

    HD 1280 x 720 (16:9) / 60p, 50p, 30p, 25p, 24p / ALL‑I(A‑I), IPB(SF, F, N) (MOV)

  •

    ALL‑I: ~ 202 Mbps

  •

    FullHD IPB (SF: ~52Mbps, F: ~30Mbps)

  •

    HD IPB (SF: ~26Mbps, F: ~14Mbps, N: ~10Mbps)

  •

    HD 1280 x 720 (16:9) / 30p (MOV)

  • Movie quality

    640 x 480 / 30p (AVI Motion JPEG®)

  • Maximum Recording Time

    29min (MOV)

  •

    14min (SD) / 7min (HD) (AVI Motion JPEG®)*

  • Max. file size

    4GB (AVCHD)

  •

    2GB (Motion‑JPEG)

  • Exposure Modes
    • Aperture priority
    • Art Filter
    • Manual
    • Programme automatic
    • Shutter priority
  •

    * Frame rate may drop when using certain art filter

  •

    Class 10 or higher SD card is recommended for movie shooting

  •

    UHS‑II or UHS‑I U3 card is recommended for ALL‑I shooting

Movie Specialties

  • Time lapse

    4k, 1080p, 720p (AVI Motion JPEG®)

  • Fast motion

    Yes

  • Slow motion

    Yes

  • Movie clips

    1, 2, 4, 8s

  •

    (Extension up to 16s by pressing record button before clip ends.)

  • Movie effects
    • Multi shot echo
    • One shot echo
    • Art fade
    • One push tele-converter
    • Old Film
  • Art Filter
    • Cross Process
    • Diorama
    • Dramatic Tone
    • Gentle Sepia
    • Grainy Film
    • Key Line
    • Light Tone
    • Pale & Light Colour
    • Pin Hole
    • Pop Art
    • Soft Focus
    • Vintage
    • Partial Colour*
  •

    * 18 colours selectable

  •

    Frame rate limited to 30fps or lower

  • HDMI Live View

    Yes (GUI* is shown on connetced device only and peaking is not available)

  •

    * GUI can be hidden for recording on external drive under following condition. Movie type: YCbCr 4:2:2 / Frame rate: as set / Sound: no

Sound Recording System

  • Internal microphone

    Stereo

  • Recording format

    Stereo PCM/16bit, 48kHz, Wave Format Base

  • Image footage

    30s

  • Speaker

    Yes

  • Microphone functions
    • Wind Noise Reduction
    • Recording Volume
    • Volume limiter
    • Audio Dubbing
  • Linking Olympus PCM Recorders
  • Functions

    Slate Tone / Synchronised Audio Rec‑Movie Rec

  •

    Compatible with: LS‑100

View Images

  • Modes
    • Index
    • Calendar
    • Zoom
    • Slide show
    • Movie
    • Single
  • Light box

    Yes

  • Histogram in playback mode

    Yes

  • Shooting information

    Off / On

  • Highlight/Shadow point warning

    Yes

Erase / Protect / Copy Function

  • Erase modes

    Single, All, Selected

  • Image protect mode

    Single frame, Selected frames, All Frames, Release protect (Single/All selected)

Image Editing

  • Editing functions
    • RAW data edit
    • Red-eye reduction
    • Sepia
    • Black & White
    • Resize
    • Correction of saturation
    • Correction of brightness
    • Correction of colour balance
    • Shadow Adjustment
    • Trimming
    • e-Portrait
    • Aspect ratio

Menu

  • Menu languages in camera

    English, French, German, Spanish, Italian, Russian, Czech, Dutch, Danish, Polish, Portuguese, Swedish, Norwegian, Finnish, Croatian, Slovenian, Hungarian, Greek, Slovak, Turkish, Latvian, Estonian, Lithuanian, Ukrainian, Serbian

Customisation Options

  • Fn Button

    Yes

  • My Mode

    4 settings storable (Can be set to mode dial.)

  • Factory reset

    Full / Basic

  • Programmable button

    Yes

Interface

  • Media

    SD Memory Card (SDHC, SDXC, UHS‑I, UHS‑II compatible) Class 10 or higher SD card is recommended for movie shooting UHS‑II or UHS‑I U3 card is recommended for 4K, C4K, ALL‑I shooting.

  •

    Slot1: UHS‑I, II compatible; Slot2: UHS‑I compatible

  • HDMI™

    Yes; Micro connector (Type D) *

  • USB 2.0 High Speed

    Yes

  • USB 3

    Type C

  • Wireless connectivity

    WiFi

  •

    * “HDMI”, the HDMI logo and “High‑Definition Multimedia Interface” are trademarks or registered trademarks of HDMI Licensing LLC.

  • Tethered control

    Yes

  • Microphone jack

    3.5 ø mm mini‑jack

  • Earphone jack

    3.5 ø mm mini‑jack

  • Synchro socket

Wi-Fi Functions

  • Easy Connection

    QR code setting

  • Wireless Shooting
    • Live View
    • Power off
    • Rec View
    • Self timer
    • Touch AF & Shutter
    • P/A/S/M exposure modes
    • Bulb mode
    • Zoom
    • Movie recording
    • Live Composite
    • Short movie

Power Supply

  • Battery

    BLH‑1 Lithium‑Ion Battery

  • Sleep mode

    1, 3, 5, 10 min. and off selectable.

  • DC-input

    AC‑5

  • Battery life
  • Image shooting

    Approx. 440 shots (using BLH‑1 and Toshiba SDHC UHS‑I Card Exceria with IS on, with no flashes attached , based on CIPA test standards) Approx. 950 shots (using quick sleep mode, under Olympus testing conditions based on CIPA test standards)

  • Movie recording

    90min (standard JEITA conditions) 150min (when zoom and other operational functions are not used)

Environment

  • Temperature

    ‑10 ‑ 40°C Operating temperature / ‑20 ‑ 60°C storage temperature

  • Humidity

    30 ‑‑ 90% operation humidity / 10 ‑ 90% storage humidity

Size

  • Dimensions (W x H x D)

    134.1 x 90.9 x 68.9mm (without protrusions)

  • Weight

    574g (including battery and memory card)

  •

    498g (body only)

Exterior

  • Available Colours

    Black

Kết quả hình ảnh cho Olympus OM-D E-M1 Mark II Review

Conclusion

The new Olympus OM-D E-M1 Mark II is a veritable speed demon, offering incredibly fast shooting rates coupled with a much improved auto-focusing system that keeps moving subjects sharp. Together with the simply amazing 5-axis image stabilisation system, which provides up to 6.5 stops of compensation with certain lenses, and a durable weather-proof body, the E-M1 Mark II is capable of successfully capturing a wide variety of subjects in almost any shooting situation that you’ll encounter. Add the fact that it delivers outstanding still image quality for a camera with such a small sensor, whilst making several leaps forward for video, and it’s clear that the OM-D E-M1 Mark II is easily the best Olympus mirrorless camera to date.

There is one rather large elephant in the room, however, and that’s the £1849/$1999 body-only price tag that Olympus have set for their new flagship model. “How much?!” has dominated Internet discussion ever since Olympus announced the launch price a few weeks ago, with the suggested RRP easily making the OM-D E-M1 Mark II the most expensive Micro Four Thirds camera, ever. Still, the OM-D E-M1 Mark II is also the fastest camera currently available, never mind the fastest Micro Four Thirds camera, easily beating DSLR or other mirrorless models, although its new AF system isn’t as refined or as accurate as the Canon’s and Nikon’s of this world. On the other hand, you do have to buy into the fact that the sensor is so much smaller than most other interchangeable lens cameras – after all that is essentially what allows the OM-D E-M1 Mark II achieve such mind-boggling speeds.

Kết quả hình ảnh cho Olympus OM-D E-M1 Mark II Review

Which is a rather roundabout way of saying that the Olympus OM-D E-M1 Mark II certainly isn’t for everyone, particularly if you won’t take advantage of the sheer raw speed. There are cameras with larger sensors and better image quality at a similar or even cheaper price-point – they just won’t be able to capture as many frames per second as the Olympus OM-D E-M1 Mark II, and therefore you may miss the moment, depending of course on what kind of subjects you shoot. As usual, there’s no such thing as the perfect camera for everyone, just the best camera for you. In our view, the Olympus OM-D E-M1 Mark II is a big step forward for Micro Four Thirds and mirrorless cameras as a whole, but it does come with a big price tag to match, so you really need to evaluate the image quality that it delivers and whether or not you’ll really take advantage of all the cutting-edge features that it offers…

(photographyblog.com, https://goo.gl/HVkBKx)

Comments

comments

Share on FacebookShare on Google+Pin on PinterestShare on StumbleUponTweet about this on TwitterShare on LinkedIn
